ATR-110U Wireless Signal Repeater

ATR-110U Wireless Signal Repeater

10mW Output | Small Area Signal Boost | Compliant with Regional Regulations

The ATR-110U is a low-power 10mW wireless signal repeater designed specifically for regions with strict RF power limitations, such as Japan and Taiwan. It effectively enhances wireless signal coverage within small areas, resolving communication dead zones caused by corners or obstacles.
This repeater is ideal for boosting low-power device communications, providing a compliant and reliable solution that meets local regulatory requirements.
  • ATR-110U-1.png
  • ATR-110U-2.png
  • ATR-110U-3.png
  • ATR-110U-4.png
  • ATR-110U-5.png
DETAIL

ATR-110U Low-Power Wireless Signal Repeater
10mW Output | Small Area Coverage Boost | Compliant with Regional Regulations

The ATR-110U is a low-power 10mW wireless signal repeater designed specifically for regions with RF power restrictions, such as Taiwan and Japan. It effectively strengthens wireless signal coverage in small areas, eliminating communication dead zones caused by corners or obstacles.

This repeater is optimized for low-power devices and provides an ideal solution for communication enhancement while meeting local regulatory requirements.

Key Advantages

  • 10mW low-power output compliant with Taiwan and Japan wireless regulations

  • Enhances signal coverage in localized dead zones, improving overall communication stability

  • Specifically designed to extend signals for low-power devices

  • Suitable for small spaces such as retail stores, offices, and dining area corners

Specifications

Parameter Details
Model ATR-110U
Frequency 429~470 MHz
Output Power 10 mW
Data Rate 1200 bps / 9600 bps
Modulation FSK
Modulation Bandwidth +/- 4.5 KHz
Channel Bandwidth 25 KHz
Harmonic Suppression Less than -25 dBm
Frequency Stability ±2 ppm (-10°C to +60°C)
RF Connector SMA (Female)
Sound Level 75 dBA @ 10 cm
Current Consumption Standby: 100 mA; Transmit: 1000 mA
Power Input 5V / 3A Adapter
Dimensions (mm) 120 × 180 × 26.5
Certifications FCC, CE, NCC
